The Suzuki F8B is a 796cc, 3-cylinder, 4-stroke petrol engine, widely used in vehicles like the Maruti 800 and Suzuki Alto (800cc). It is a SOHC (Single Overhead Camshaft) design, featuring 6 valves (2 per cylinder), a 68.5mm bore, 72mm stroke, and a, 8.8:1 compression ratio, producing approximately
32–40 hp and 54–62 Nm of torque.
Key Technical Parameters (Suzuki F8B):
-
Engine Type: 3-cylinder, Inline (Straight), 4-stroke
-
Displacement: 796 cc (0.8L)
-
Valvetrain: SOHC, 6 Valves (2 valves per cylinder)
-
Bore x Stroke:
68.5mm×72mm68.5 mm cross 72 mm
68.5mm×72mm
-
Compression Ratio: 8.8:1
-
Power Output: ~32–40 HP (24–30 kW) @ 5,500–6,000 RPM
-
Torque Output: ~54–62 Nm (40–46 lb-ft) @ 3,000–3,500 RPM
-
Fuel System: Carburetor (commonly Mikuni) or MPFI (Multi-Point Fuel Injection)
-
Cooling System: Water-cooled
-
Firing Order: 1-3-2
-
Oil Capacity: ~2.7 Liters (20W40/10W30)
Common Applications:
|
