1KD/2KD发动机凸机 |

Production years
2001-present
Cylinder block material
Cast iron
Cylinder head material
Aluminum
Fuel type
Diesel
Fuel system
Common rail direct injection
Configuration
Inline
Number of cylinders
4
Valves per cylinder
4
Valvetrain layout
DOHC
Bore, mm
92.0 mm (3.62 in)
Stroke, mm
93.8 mm (3.69 in)
Displacement, cc
2,495 cc (152 cu in)
Type of internal combustion engine
Four-stroke, turbocharged
Compression Ratio
18.5:1 - 2001-2004
17.4:1 - 2005+
Power, hp
101-188 hp (75-140 kW)/3,400
Torque, lb ft
200-420 lb-ft (148-310 Nm)/1,600-3,600
Engine weight
-
Firing order
1-3-4-2
Engine oil weight
SAE 5W-30
Engine oil capacity, liter
6.9 (7.3 qt) - service fill
0.3 (0.33 qt) - oil filter.
Oil change interval, mile
9,000 (15,000 km) / 12 months
Applications
Toyota Hilux, Toyota Fortuner, Toyota Innova, Toyota Hiace, Toyota 4Runner
|
