1AZ/2AZ  |
Production years
2000-present day
Cylinder block material
Aluminum
Cylinder head material
Aluminum
Fuel type
Gasoline
Fuel system
Fuel injection
Configuration
Inline
Number of cylinders
4
Valves per cylinder
4
Valvetrain layout
DOHC
Bore, mm
88.5
Stroke, mm
96.0
Displacement, cc
2362
Type of internal combustion engine
Four-stroke, naturally aspirated
Compression Ratio
9.6:1
9.8:1 (since 2008)
Power, hp
160 hp (120 kW)/5,600
Torque, lb ft
162 lb-ft (220 Nm)/4,000
Engine weight
305 lbs (138 kg)
Firing order
1-3-4-2
Engine oil weight
5W-30, 10W-30
Engine oil capacity, liter
4.3
Oil change interval, mile
6,000 (10,000 km) or 12 month
Applications
Toyota Camry, Toyota Matrix S (USA)/XR (Canada)/XRS, Pontiac Vibe, Toyota Corolla XRS, Toyota Camry Solara, Toyota RAV4, Toyota Highlander/Kluger/Harrier, Toyota Estima/Ipsum/Previa/Tarago, Toyota Alphard, Toyota Blade, Toyota Avensis, Scion tC, Scion xB, Toyota MarkX Zio
|
